Instruments

If you would like to use any of our instruments, please get in touch with Anjali at anjali.anilkumar[at]uni-saarland.de or Tel.: +49 (0)681 / 302-68561

Our microscopes are part of the High Resolution Microscopy Facility.

Nikon AXR fast confocal microscope

The Nikon AXR fast confocal microscope is an inverted motorized scientific microscope with Laser unit (405nm/488nm/561nm/640nm lasers) and Galvano Scanner.

Objectives

Air objective 20X
Extra-long working distance objective 40x with phase contrast
Water immersion objective 40x
Oil immersion objective 100X

Fluorescence filter blocks available:

Filter block for DAPI, Hoechst, AMCA, BFP, Alexa Fluor 350 (EX 387/11; DM 409; BA 447/60 for higher contrast)
Filter block for GFP, eGFP, DiO, Cy2, YOYO-1, YO-PRO-1 (EX 466/40; DM 495; BA 525/50 for a brighter image)
Filter block for mCherry, mRFP. (EX 562/40; DM 593; BA 640/75)
Filter block for Cy5, APC, DiD, Alexa 647, Alexa 660 (EX 628/40; DM 660; BA 692/40)

Zeiss Axiovert 200M

Epifluorescence Microscope

The Axiovert 200M is a widefield microscope for routine imaging.
Epifluorescence light path with DAPI, FITC, Rhodamine, Cy5 filters.

Objectives:

Fluor 5x NA0.25
PlanApo 20 Imm
Apo 40 air
PlanApo 63/1.40 OilPH3

Motorized Z-drive
Sideport Left 100%/Right100%/VIS100%
Motorized condenser
Manual stage with adjustable stage insert.
Light Source: CoolLED pE300 Ultra MB
JetCam 19 Mono
KY-FGF-II-CLHSKomodo Fiber CLHS Frame Grabber

Clariostar Plus

Plate Reader

The Clariostar Plus is equipped with with advanced LVF Monochromators, highly sensitive filters, and an ultra-fast UV-vis spectrometer.

Full instrument information here.

Gonotec Osmomat 3000

Osmometer

The Osmomat determines the total osmolality of aqueous solutions by comparative measurements of the freezing point compared to pure water. The instrument requires very small sample volumes and can thus be applied for extreme measuring tasks. Its rapid readings allows serial measurements in a very short time.

Full instrument details here.
